$6,698.00

2008 KTM 250 SX-F
Request a Quote Financing Calculator Request a Brochure Financing Form
Request a Quote Financing Calculator Request a Brochure Financing Form
  • OEM Overview
  • Specifications
  • Compare Models
  • Current Promotions

Overview

 Print Brochure

Winning technology that inspires: with an innovative 250cc four-stroke engine that hauls abundant power up out of the lowest rpms and delivers its unbelievable punch all the way up to the limit. And this bike’s appearance also delivers everything. A new, super-lightweight chassis complements the complete update of the bodywork to become an unbeatable unit. The 250 SX-F – for sure the hottest contender for the World Championship podium.

    Engine
    • Engine type: Single cylinder, 4-stroke
    • Displacement: 248.6 cc
    • Bore x stroke: 76 x 54.8 mm (2.99 x 2.16")
    • Compression ratio: 12.8:1
    • Starter: Kickstarter
    • Transmission: 6 gears
    • Carburetor: Keihin MX FCR 39
    • Control: 4 V / DOHC
    • Lubrication: Pressure lubrication
    • Engine lubrication: 10W50
    • Primary drive: 22:68
    • Final drive: 13:48
    • Cooling: Liquid cooled
    • Clutch: Wet multi-disc clutch, operated hydraulically
    • Ignition: Kokusan digital magneto CDI
    Chassis
    • Frame: Central double-cradle-type 25CrMo4
    • Subframe: Aluminium 7020
    • Handlebar: Renthal Aluminium Ø 28/22 mm (1.10/0.87")
    • Front suspension: WP USD Ø 48 mm (1.89")
    • Rear suspension: WP monoshock PDS
    • Suspension travel front / rear: 300 / 335 mm (11.81 / 13.19")
    • Brakes, front / rear: Disc brakes 260 / 220 mm (10.24 / 8.66")
    • Rims, front / rear: 1.60 x 21"; 2.15 x 19"
    • Tires, front / rear: 80/100-21"; 100/90-19"
    • Chain: 5/8 x 1/4"
    • Main silencer: Aluminium
    • Steering head angle: 63.5°
    • Wheel base: 1475±10 mm (58.07±0.39")
    • Ground clearance (unloaded): 380 mm (15")
    • Seat height: 925 mm (36.42")
    • Fuel capacity: approx. 7,2 liters (1.9 gal)
    • Weight (no fuel): approx. 98 kg (216 lbs)

    Specifications

    Engine
    Engine Type Single cylinder, 4-stroke
    Displacement 248.6 cc
    Bore and Stroke 76 x 54.8 mm (2.99 x 2.16 in.)
    Cooling Liquid
    Compression Ratio 12.8:1
    Fuel System Keihin FCR MX 39
    Ignition Kokusan
    Chassis
    Front Suspension WP USD Ø 1.89 in. (48 mm)
    Front Brakes Disc brakes 10.24 in. (260 mm)
    Front Tire 80/100-21 in.
    Rear Suspension WP PDS shock absorber
    Rear Brakes Disc brakes 8.66 in. (220 mm)
    Rear Tire 100/90-19 in.
    Dimensions
    Dry Weight 216 lbs (98 kg)
    Fuel Capacity 2.11 gal (8 l)
    Wheelbase 58.07 ± 0.39 in. (1475 ±10 mm)
    Ground Clearance 15 in. (380 mm)
    Seat Height 38.78 in. (985 mm)
    Rake 63.5°
    Transmission
    Transmission 6 gears
    Final Drive 13:48

    Compare Models

    		 Print








    Year 2008
    Manufacturer KTM
    Model 250 SX-F
    Style Off-Road
    Chassis
    Front Suspension WP USD Ø 1.89 in. (48 mm)
    Front Brakes Disc brakes 10.24 in. (260 mm)
    Front Tire 80/100-21 in.
    Rear Suspension WP PDS shock absorber
    Rear Brakes Disc brakes 8.66 in. (220 mm)
    Rear Tire 100/90-19 in.
    Dimensions
    Dry Weight 216 lbs (98 kg)
    Fuel Capacity 2.11 gal (8 l)
    Wheelbase 58.07 ± 0.39 in. (1475 ±10 mm)
    Ground Clearance 15 in. (380 mm)
    Seat Height 38.78 in. (985 mm)
    Trail
    Rake 63.5°
    Engine
    Engine Type Single cylinder, 4-stroke
    Displacement 248.6 cc
    Bore and Stroke 76 x 54.8 mm (2.99 x 2.16 in.)
    Cooling Liquid
    Compression Ratio 12.8:1
    Fuel System Keihin FCR MX 39
    Ignition Kokusan
    General
    Colors
    Warranty
    Transmission
    Transmission 6 gears
    Final Drive 13:48
